KEY FEATURES

• Super Rollers standard provide premium wear life with options available in Poly and PTFE for superior chemical resistance
• Viton seals offer the best overall chemical resistance
• Clockwise shaft rotation directly couples to gas engines and electric motors
• Counter-clockwise shaft rotation is available for PTO adaption
• 5/8 in. solid stainless steel shaft resists corrosion

MATERIALS

Cast Iron pumps lasted to 140 hours before failure

SPECIFICATIONS

MAX FLOW: 7 gpm/26.5 lpm at 2600 rpm
MAX PRESSURE: Continuous 100 psi/6.9 bar, Intermittent 150 psi/10.3 bar
MAX RATED SPEED: 2600 rpm
MAX FLUID TEMPERATURE: 140 degrees Fahrenheit/60 degrees Celsius
PORT SIZE: 3/4 in. NPT
PUMP SHAFT: 5/8 in. solid stainless steel (1/2 in. hollow available)
PUMP SHAFT ROTATION: CW (CCW available)
HOUSING and ROTOR: Cast Iron (C), Ni-Resist (N) or Silvercast (XL)
ROLLERS: Super Rollers standard [Poly (T3) and Teflon (T2) available]
SHAFT SEALS: Viton standard
WEIGHT: 5 lbs./2.27 kg
